1000 Watts Solar Panel Wind Turbine Hybrid Kit: 6 pcs 100W Solar Panel +400W Wind Turbine Generator for Home House for 24V Battery

Package include:
* 6x100W Poly solar panel,( 90cm of special cable with F/M connectors attached )
* 1x 400W Wind Turbine
* 1x 50A 12V/24V LCD Solar Controller
* 1x Wind controller
* 1x 6 in 1 F/M connectors
* 1x Totally 3m battery cable( red about 1.5m , black about 1.5m)
* 1x Totally 5m extension cable with F/M connectors ( red about 2.5m, black about 2.5m)

Note
Please advise if you need 12V system or 24V system when place order.

Solar Wind hybrid kit will be delivered in separate packages due to the size restriction by shipping courier.

* 100W Poly Solar Panel Specification:
Maximum Power: 100W
Optimum Operating Voltage (Vmp): 18 V
Open-Circuit Voltage (Voc): 21.6 V
Optimum Operating Current (Imp): 5.55 A
Short-Circuit Current (Isc): 6.11A
Dimensions: 1025*671*30mm / 40.35 X 26.42 X1.18 In
Weight: 16.53 lbs (7.5KG)
90cm of special cable with F/M connectors attached.

400W Wind Turbine Specification:
Rated power: 400W
Rated voltage DC27-54V
Battery voltage: DC 12/24V
Start-up wind speed: 2.5m/s
Rated wind speed: 10.5m/s
Number of blades: 5
Material of wind leaf: carbon fiber composite
Rotor diameter: 1.2M
Rated speed: 800MINRPM
Net weight: 8KG

Additional details

• Material Type : Aluminum

Features & Specs

• Amperage Capacity : 5.55 Amps
• Connector Type : USB
• Efficiency : High Efficiency
• Maximum Power : 100 Watts
• Maximum Voltage : 24 Volts
• Special Features : high module conversion efficiency, excellent performance in low light conditions, corrosion-resistant aluminum frame, five-blade design with a low start-up speed, patented permanent magnet generator, special stator

Item details

• ASIN : B09WQYTRQR
• Brand Name : AUECOOR
• Included Components : 6 x 100W Poly solar panels, 1 x 400W Wind Turbine, 1 x 50A 12V/24V LCD Solar Controller, 1 x Wind controller, 1 x 6 in 1 F/M connectors, 1 x Totally 3m battery cable, 1 x Totally 5m extension cable with F/M connectors
• Manufacturer : AUECOOR
• Manufacturer Part Number : AUE-APVP-1000hybrid-KIT-N
• Model Number : 701871937463
• UPC : 701871937463

Measurements

• Item Dimensions L x W x H : 40.35'L x 26.42'W x 40.35'H
• Item Weight : 16.53 Pounds
